Stainless Steel Pipe Fittings

Step into the future with our Forged Fittings, expertly crafted and delivered by an elite manufacturer, supplier, and trader with over 7 years of unrivaled industry experience. Experience the exceptional quality of our Stainless Steel Forged Fittings, Carbon Steel Forged Fittings, Nickel Alloy Forged Fittings, and Inconel Forged Fittings, which are engineered for strength, precision, and long-lasting reliability. These superb fittings boast five elite advantages:: unmatched corrosion resistance for longevity, outstanding mechanical strength, superior dimensional accuracy for perfect fitment, high-pressure resistance for safety, and seamless compatibility with a wide range of industrial applications. What sets our offerings apart is the instant savings, with exclusive sale prices and top-notch offers for clients seeking value and performance. Choose our forged fittings for application versatility-be it petrochemical, power generation, marine, or construction sectors-ensuring your operations run efficiently and cost-effectively. We guarantee supply ability across All India, ensuring prompt and reliable delivery. Trust the industry-leading expertise and advanced technology of our company to provide forged fittings that are a cut above the rest, delivering exceptional value and reliability unmatched by ordinary competitors.
SS304 Stainless Steel Elbow

SS304 Stainless Steel Elbow

  • Application
  • other, Oil & Gas / Water Supply / Chemical Industry
  • Bend Radius
  • Standard (1D, 1.5D, 3D available)
  • Coating Type
  • Optional Black Paint or Uncoated
  • Color
  • Metallic Silver / Black
  • Connection
  • Other, Welded / Butt Weld
  • Connection Type
  • Butt Weld, Socket Weld
  • Diameter
  • 1/2" - 24" (DN15 - DN600)
  • Flexibility
  • Rigid
  • Length
  • Custom as per specification
  • Material
  • Other , SS304 Stainless Steel
  • Material Grade
  • 304 / 304L
  • Outer Diameter
  • 1/2 inch to 24 inch
  • Product Type
  • Other, Stainless Steel Elbow
  • Rated Pressure
  • Up to 20 bar (as per dimension)
  • Sealing Type
  • Metal-to-Metal Seal
  • Section Shape
  • Round
  • Shape
  • Other, Elbow (Curved)
  • Standard
  • Other, ASTM A403 / ASME B16.9
  • Surface Treatment
  • Other, Pickled / Polished / Black Painted
  • Temperature Range
  • -50C to +800C
  • Tensile Strength
  • 515 MPa Min
  • Thickness
  • 2 mm - 10 mm (varies by size)
  • Thread Type
  • Not Threaded (Weld Type)
  • Tolerance
  • 0.5 mm
  • Usage
  • Pipeline Fitting, Plumbing, Industrial Applications
  • Yield Strength
  • 205 MPa Min
Know more
SS316 Stainless Steel Elbow

SS316 Stainless Steel Elbow

  • Application
  • other, Oil & Gas, Petrochemical, Food Processing, Chemical, Construction
  • Bend Radius
  • 1D, 1.5D, 2D (as per requirement)
  • Coating Type
  • None / Pickled
  • Color
  • Metallic Silver / Black finish
  • Connection
  • Other, Welded or Socket Weld
  • Connection Type
  • Butt Weld / Socket Weld
  • Diameter
  • Nominal diameter as per specification
  • Flexibility
  • Rigid
  • Length
  • Seam Center to End: as per standard
  • Material
  • Other , SS316 Stainless Steel
  • Material Grade
  • SS316
  • Outer Diameter
  • 1/2 inch to 24 inch (customizable)
  • Product Type
  • Other, Pipe Elbow
  • Rated Pressure
  • Up to 40 bar
  • Sealing Type
  • Metal to Metal
  • Section Shape
  • Round
  • Shape
  • Other, Elbow (Curved)
  • Standard
  • Other, ASTM A403 / ASME SA403
  • Surface Treatment
  • Other, Shot Blasted / Pickled
  • Temperature Range
  • -50C to +800C
  • Tensile Strength
  • 515 MPa min
  • Thickness
  • 3 mm to 10 mm (customizable)
  • Thread Type
  • Not Applicable (for welded elbows)
  • Tolerance
  • 0.5 mm
  • Usage
  • Industrial Pipe Fitting
  • Yield Strength
  • 205 MPa min
Know more
